Features ( some of )



    * A digital meter is used in order to ensure precision and ease-of use in the vertical cutting.

    * Vertical and horizontal movements are performed on linear skids at a precision of 0.01 mm.

    * There is a magnifying glass on figures on vertical and horizontal meters to ensure a good reading.

    * The cutting mechanism which horizontally moves is locked very easily only by pneumatically pushing a single-button.

    * All surfaces move up and down during the horizontal cutting process automatically in a manner not to give harm to the cutting process.

    * The cutting unit is moved to the left and right and backward and forward on a single push-button.

    * Aluminium profiles used horizontally and vertically are applied as they require precision due to their own structures.

    * The cutting unit is moved up and down easily thanks to a manual balancing system.

    * A high-power engine for 5.5 Hp-6000 d/d. 380 Volt with a belt and pulley system and high-torque engine system.

    * The cutting unit converts from the vertical cutting to the horizontal cutting easily thanks to its special rotation and locking mechanism.

    * The metal rolling system that has ball-bearings ensuring a great number of circulations provides a quick movement.

    * The adjustment for the saw perpendicularity is easily fixed with an adjustment screw.

    * It can be immersed into the desired depth thanks to its seam support disk.

    * It is fixed onto the working area after the miter adjustment is made to ensure the machines precision.

    * The cutting unit is adjusted to a pneumatic measurement into a depth in a forward and backward movement.





Technical Specifications





    * Overall Dimensions (Length x Height x Depth)  : 4800 x 3200 x 1500 mm

    * Maximum Vertical Cutting Length : 2200 mm

    * Maximum Horizental  Cutting Length : 4000 mm

    * Maximum Cutting Thickness : 60 mm

    * Cutting Precision : 0.01 mm

    * Saw Outer Diameter : 250 mm

    * Saw Engine : 380volt - 3.7 kw - 6000 r.p.m

    * Weight : 720 Kg

    * Motor : Made In Italy

    * Control board Parts : Western Europe





Purposes of use:



    * Aluminium Composite Panels

    * Plywood

    * Fibre Board

    * All Plastic-Based Panels

    * Metal Panels (non ferrous)

    * Melamine

    * Poly-carbonated Sheets

    * Plexi Glass

    * Laminate
